Equipment platform · YGZ-HZZ Series
Tracking Piston Filling Machine
Coordinates tracking filling heads with bottles while servo pistons meter the liquid. Bottle-format settings and accumulation-stop control support line operation.
- Servo piston metering
- Bottle detection with no-bottle/no-fill control
- Stored bottle-format parameters
- Standalone operation or bottling-line integration
- Tracking nozzle positioning
- Automatic stop on bottle accumulation
Final performance, materials, utilities and acceptance criteria depend on the confirmed product and technical agreement.
Equipment configuration
Confirm output, accuracy, utilities, dimensions and acceptance criteria for the actual product, containers and line conditions.
Operating principle
- Filling heads
- 8 / 10 / 12
Standard specifications are reference values. Final output, accuracy, product compatibility and utilities require actual samples, trial conditions and the agreed technical specification.
- Filling range
- 100–1000 mL
Other ranges require a separately confirmed configuration.
- Reference output
- 80–120 bottles/min
Depends on filling heads, product behavior, fill volume and containers. Confirm by trial.
- Reference filling accuracy
- Within ±1%
Confirm the measurement method and actual product/container trial conditions.
- Bottle range
- Ø30–80 mm; H50–200 mm
Other formats require sample review and a confirmed configuration.
- Power supply
- 3-phase 380 V / 50 Hz
Standard specifications are reference values. Final output, accuracy, product compatibility and utilities require actual samples, trial conditions and the agreed technical specification.
- Air pressure
- 0.5–0.7 MPa
Standard specifications are reference values. Final output, accuracy, product compatibility and utilities require actual samples, trial conditions and the agreed technical specification.
- Power
- 6.5 kW
Standard specifications are reference values. Final output, accuracy, product compatibility and utilities require actual samples, trial conditions and the agreed technical specification.
- Dimensions (L × W × H)
- 5000 × 1550 × 2350 mm
Standard specifications are reference values. Final output, accuracy, product compatibility and utilities require actual samples, trial conditions and the agreed technical specification.
- Weight
- Approx. 1000 kg
Standard specifications are reference values. Final output, accuracy, product compatibility and utilities require actual samples, trial conditions and the agreed technical specification.
Equipment comparison
Related equipment
Compare other equipment in the same category or connected process. Suitability depends on your product, packaging and line scope.
YGZ-HDZ Series
Independent Tracking Piston Filling Machine
Independently tracking heads with servo piston metering.
View equipment detailsBuyer questions
Questions to resolve before equipment selection.
Review product suitability, configuration choices and the information needed for a proposal based on your production requirements.
How are the final specifications confirmed?
Standard specifications are reference values. Final output, accuracy, product compatibility and utilities require actual samples, trial conditions and the agreed technical specification.
Can it connect to an existing line?
Standalone use or line integration can be evaluated. Confirm conveyor direction, height, speed, interlocks and available space before ordering.
